Made In China GCR15 Agricultural Machinery Bearing FD211-1 3/4HX
FD-211-RKB Certified ISO9001
FD211-1 3/4HX Agricultural Machinery Bearing
44.450*139.7*114.3mm Bearing Features:
Inner Ring Diameter (bore):1.750 Inch
Outer Ring Diameter: 5.5 Inch
Width:4.5 Inch
FD211-1 3/4HX Agricultural Machinery Bearing Description:
| Model Number | FD211-1 3/4HX |
| Inside Diameter: | 1 3/4 |
| Outside Diameter: | 5 1/2 |
| Thickness: | 4 1/2 |
| Seal Type: | Double Shielded, 2RS |
| Material: | Chrome steel, Gcr15 |
| Precision Rating: | P0-P5 |
| Brand: | TOPE or other brands |
| Payment term: | T/T,L/C,Western Union, PayPal |
| Delivery time: | 1-5 days for small amout, 15-40 days for big amount |
FD211-1 3/4HX Agricultural Machinery Bearing
more models:
| Bearing type | Style | Trunnion | A | B | C | D | E | F | G |
| ST491A | 2 | 1 3/4 RD | 1.687 | 4.000 | 5.000 | 5.000 | 0.531 | | |
| ST491B | 4 | 1 1/2 RD | 1.687 | 4.000 | 5.000 | 5.000 | | 0.531 | 0.687 |
| FD209-1 1/8SQ | 3 | 1 1/8 SQ | 1.687 | 4.000 | 5.000 | 5.000 | | 0.531 | 0.687 |
| FD209-1 1/4SQ | 3 | 1 1/4 SQ | 1.687 | 4.000 | 5.000 | 5.000 | | 0.531 | 0.687 |
| FD211-1 1/2SQ | 3 | 1 1/2 SQ | 2.000 | 4.500 | 5.500 | 5.500 | | 0.531 | 0.687 |
| FD211-1 3/4RD | 2 | 1 3/4 RD | 2.187 | 4.500 | 5.500 | 5.500 | 0.531 | | |
| FD211-1 3/4HX | | 1 3/4 HX | 2.188 | 4.500 | 5.500 | 5.500 | 0.531 | | |
| FD211-1 15/16RD | 2 | 1 15/16 RD | 2.187 | 4.500 | 5.500 | 5.500 | 0.531 | | |
| FD211-1 15/16RDC* | | 1 15/16 RD | 2.125 | 4.500 | 5.500 | 5.500 | 0.531 | | |
| FD211-2 3/16RD | 2 | 2 3/16 RD | 2.187 | 4.500 | 5.500 | 5.500 | 0.531 | | |
FD211-1 3/4HX Agricultural Machinery Bearing Applications:
1. Plough disc connection bearing
2. Tillers, tractors, lawn harvesters,
3. Balers and high-power harvesting machines
4. Such as green feed harvesters and combine harvesters
FD211-1 3/4HX Agricultural Machinery Bearing Advantages:
1. Ability to withstand sustained vibration and high impact loads
2. Well-designed and high-precision sealing concept, which can
operate reliably under various weather conditions
3. Low maintenance or maintenance-free design to ensure high
utilization of the machine easy to install.
4. Usually it can provide the whole unit or special design, while
the structure is very simple.
Shipping Methods:
1. For small amount (GW<100KGS), we can send you by express,
such as DHL, Fedex, TNT etc
2. For GW between 100KGS to 500KGS, we can send you by sea shipping
or air shipping
3. For large amount (GW > 500KGS), we can send you by sea
Quality In Everything We Do:
1. Suppliers quality: working only with the best
Our Supplier Quality and Development (SQD) division guarantees the
flawless supply of highest quality raw materials and components.
Process quality: accurate, on-time production.
All manufacturing facilities employ a Lean approach in
manufacturing, involving every team member in a philosophy of
continuous improvement. We have state-of-the-art production lines
in all our plants. The integrated manufacturing process controls
enable us to check 100% of the parts at every critical production
step.
2. OEM-Quality Products
We deliver our products to leading global manufacturers of
transmissions, axles, differentials, and fluid pumps amongst
others; these customers use our products directly or integrate them
into their Original Equipment.
How to place an order:
1. Send us your bearing inquiry, including your bearing models,
your quantity. If you have brand requirement, please tell us which
brand do you need as well.
2. We will quote bearing price for you. Moreover, According to the
quantity of goods, we will give you different options of
transportation.
3. If you agree with our price, we will make proforma invoice for
payment.
4. After payment is done, we will start to prepare bearings and
arrange shipment.
FAQ:
Q: Are you a trading company or a factory?
A: We have both. We are trading company and we have own factory.
Q: What is the delivery time if we place an order?
A: For small orders, our delivery time is 3 days. If the amount is
large, usually our delivery time is 7-20 days.
Q: What is your payment term?
A: We accept T/T, W/U, PayPal and L/C.
Q: Do you have a warranty on bearings?
Answer: In normal use, our bearing guarantee period is 1 year.
