N312E 6013031mm Metal Roller Bearings / Industrial Roller Bearings Single Row

N312E 60*130*31mm Single Carton Pack Bearing Steel Cylindrical Roller Bearings Certified ISO9001

60*130*31mm Bearing Features:

Inner Ring Diameter (bore):60mm

Outer Ring Diameter:130mm

Width:31mm

Dynamic load:150Kn

The static load:156Kn

N312E Cylindrical Roller Bearings:

N312E 60*130*31mm Metal Roller Bearings / Industrial Roller Bearings Single Row

N312E Cylindrical Roller Bearing Description:

Model Number:	N312E
Inside Diameter:	60mm
Outside Diameter:	130mm
Width:	31mm
Seal Type:	Double Shielded, 2RS
Material:	Chrome steel, Gcr15
Precision Rating:	P0-P5
Brand:	TOPE or other brands
Payment term:	T/T,L/C,Western Union, PayPal
Delivery time:	1-5 days for small amout, 15-40 days for big amount

more models:

Bearing	d	D	B	rsmin	Ew	Fw	Mass	CrKN	CorKN	Limiting	D1min	D1max	D2min	D3min	D4max
Code										speed
N202E	15	35	11	0.6	30.3	19.3	0.047	12.7	10.4	22000	17.4	18.5	20	22	32.6
N203E	17	40	12	0.6	35.1	22.1	0.068	17.6	14.6	18000	21	21.5	23	28	36
N204E	20	47	14	1	41.5	26.5	0.112	27.5	24.5	16000	24	26	29	32	41
N205E	25	52	15	1	46.5	31.5	0.135	29	27.5	15000	29	31	34	37	46
N206E	30	62	16	1	55.5	37.5	0.205	39	37.5	12000	34	37	40	44	56
N207E	35	72	17	1.1	64	44	0.301	50	50	10000	39	43	46	50	65
N210E	50	90	20	1.1	81.5	59.5	0.488	64	68	8000	57	58	62	67	83
N211E	55	100	21	1.5	90	66	0.668	83	95	7000	62	65	68	73	91
N212E	60	110	22	1.5	100	72	0.827	95	1.4	6300	69	71	75	80	101
N212E	60	110	22	1.5	100	72	0.827	95	1.4	6300	69	71	75	80	101
N213E	65	120	23	1.5	108.5	78.5	1.05	108	120	6000	74	77	81	87	111
N213E	65	120	23	1.5	108.5	78.5	1.05	108	120	6000	74	77	81	87	111
N214E	70	125	24	1.5	113.5	83.5	1.16	120	137	5300	79	82	86	92	116
N215E	75	130	25	1.5	118.5	88.5	1.29	132	156	5300	84	87	90	96	121
N216E	80	140	26	2	127.3	95.3	1.55	140	170	4800	91	94	97	104	129
N217E	85	150	28	2	136.5	100.5	1.92	163	193	4500	96	99	104	110	139
N218E	90	160	30	2	145	107	2.37	183	216	4300	101	105	109	116	149
N219E	95	170	32	2.1	154.5	112.5	2.89	220	265	3800	107	111	116	123	158
N220E	100	180	34	2.1	163	119	3.5	250	3.5	3800	112	117	122	130	168
N221E	105	190	36	2.1	171.5	125.5	4.63	260	320	5600	117	123	128	137	178
N222E	110	200	38	2.1	180.5	132.5	6.87	290	365	3400	122	130	135	144	188
N224E	120	215	40	2.1	195.5	143.5	5.67	335	415	3200	132	141	146	156	203
N226E	130	230	40	3	209.5	153.5	6.51	360	450	3000	114	151	158	168	216
N228E	140	250	42	3	225	169	9.29	390	510	4800	154	166	171	182	236
N230E	150	270	45	3	242	182	15.9	440	585	4500	164	179	184	196	256
N232E	160	290	48	3	259	195	14.6	500	670	4300	174	192	197	210	276
N234E	170	310	52	4	279	207	18.1	585	780	3600	187	204	211	223	293
N238E	190	340	55	4	306	230	22.8	680	930	3200	207	227	234	247	323
N240E	200	360	58	4	323	243	30.6	750	1040	3000	217	240	247	261	343
N248E	240	440	72	4	393	293	51.5	1140	1600	2600	257	290	296	315	423
N305E	25	62	17	1.1	54	34	0.242	41.5	37.5	12000	32	33	37	40	55
N306E	30	72	19	1.1	62.5	40.5	0.366	51	48	10000	37	40	44	48	65
N309E	45	100	25	1.5	88.5	58.5	0.891	98	100	6700	54	57	60	66	91
N310E	50	110	27	2	97	65	1.16	110	114	6300	61	63	67	73	99
N311E	55	120	29	2	106.5	70.5	1.48	134	140	5600	66	69	72	80	109
N311E	55	120	29	2	106.5	70.5	1.48	134	140	5600	66	69	72	80	109
N312E	60	130	31	2.1	115	77	1.84	150	156	5000	72	75	79	86	118
N312E	60	130	31	2.1	115	77	1.84	150	156	5000	72	75	79	86	118
N313E	65	140	33	2.1	124.5	82.5	2.28	180	190	4800	77	81	85	93	128
N313E	65	140	33	2.1	124.5	82.5	2.28	180	190	4800	77	81	85	93	128
N314E	70	150	35	2.1	133	89	2.79	204	220	4500	82	87	92	100	138
N315E	75	160	37	2.1	143	95	3.34	240	265	4000	87	93	97	106	148
N316E	80	170	39	2.1	151	101	4.12	255	275	3800	92	99	105	114	158
N317E	85	180	41	3	160	108	5.3	290	325	5600	99	106	110	119	166
N318E	90	190	43	3	169.5	113.5	6.19	315	345	5300	104	111	117	127	176
N319E	95	200	45	3	177.5	121.5	7.04	335	380	5300	109	119	124	134	186
N320E	100	215	47	3	191.5	127.5	8.75	380	425	5000	114	125	132	143	201
N322E	110	240	50	3	211	143	11.7	440	510	4800	124	140	145	158	226
N324E	120	260	55	3	230	154	15.1	520	600	4500	134	151	156	171	246
N326E	130	280	58	4	247	167	18.4	610	720	4300	147	164	169	184	263
N328E	140	300	62	4	264	180	22.5	670	800	3800	157	176	182	198	283
N330E	150	320	65	4	283	193	26.8	765	930	3600	167	190	195	213	303
N332E	160	340	68	4	300	204	32.6	865	1060	3000	177	200	211	228	323
N334E	170	360	72	4	318	218	37.9	965	1220	3000	187	215	221	240	343

Bearing	d	D	B	rsmin	Ew	Fw	Mass	CrKN	CorKN	Limiting	D1min	D1max	D2min	D3min	D4max
Code										speed
N202E	15	35	11	0.6	30.3	19.3	0.047	12.7	10.4	22000	17.4	18.5	20	22	32.6
N203E	17	40	12	0.6	35.1	22.1	0.068	17.6	14.6	18000	21	21.5	23	28	36
N204E	20	47	14	1	41.5	26.5	0.112	27.5	24.5	16000	24	26	29	32	41
N205E	25	52	15	1	46.5	31.5	0.135	29	27.5	15000	29	31	34	37	46
N206E	30	62	16	1	55.5	37.5	0.205	39	37.5	12000	34	37	40	44	56
N207E	35	72	17	1.1	64	44	0.301	50	50	10000	39	43	46	50	65
N210E	50	90	20	1.1	81.5	59.5	0.488	64	68	8000	57	58	62	67	83
N211E	55	100	21	1.5	90	66	0.668	83	95	7000	62	65	68	73	91
N212E	60	110	22	1.5	100	72	0.827	95	1.4	6300	69	71	75	80	101
N212E	60	110	22	1.5	100	72	0.827	95	1.4	6300	69	71	75	80	101
N213E	65	120	23	1.5	108.5	78.5	1.05	108	120	6000	74	77	81	87	111
N213E	65	120	23	1.5	108.5	78.5	1.05	108	120	6000	74	77	81	87	111
N214E	70	125	24	1.5	113.5	83.5	1.16	120	137	5300	79	82	86	92	116
N215E	75	130	25	1.5	118.5	88.5	1.29	132	156	5300	84	87	90	96	121
N216E	80	140	26	2	127.3	95.3	1.55	140	170	4800	91	94	97	104	129
N217E	85	150	28	2	136.5	100.5	1.92	163	193	4500	96	99	104	110	139
N218E	90	160	30	2	145	107	2.37	183	216	4300	101	105	109	116	149
N219E	95	170	32	2.1	154.5	112.5	2.89	220	265	3800	107	111	116	123	158
N220E	100	180	34	2.1	163	119	3.5	250	3.5	3800	112	117	122	130	168
N221E	105	190	36	2.1	171.5	125.5	4.63	260	320	5600	117	123	128
