Tapered Roller Bearing LM11949 GCR15 NSK Low Power Consumption Certified ISO9001

19.05*42.237*15.494mm Bearing Features:

Inner Ring Diameter (bore):0.750 Inch

Outer Ring Diameter:1.662 Inch

Width:0.610 Inch

Bearing Weight:0.125KG

LM11949 Tapered Roller Bearing Description:

LM11949 Tapered Roller Bearing:

more models:

LM11949 Tapered Roller Bearing Classification:

1. Single row tapered roller bearing

2. Double row tapered roller bearings

3. The four column tapered roller bearings

4. Multi-Sealed Double-row and Four-row Tapered Roller Bearings

Product Details

Tapered Roller Bearings - TS (Tapered Single) Imperial/Metric

These bearings are the most basic and most widely used type of tapered roller bearings. They consist of two main separable parts, the cone (inner ring) assembly and the cup (outer ring). They are typically mounted in opposing pairs on a shaft.

Features and Benefits

• Imperial / Metric • One piece stamped steel cage retains rollers on the cone

• Inner diameter range 7.937 mm to 863.600 mm

• Outer diameter range 31.991 mm to 1060.000 mm

• Single cone and cup

Product Application Information

Typical applications include, vehicle front wheels

LM11949 Tapered Roller Bearing Structural Features:

1. The type code of tapered roller bearings is 30000, and tapered roller bearings are separated bearings. Generally speaking, especially in GB/T307.1-94 "Tolerance of Rolling Bearing Centrifugal Bearing", the outer ring and inner assembly of tapered roller bearings are 100% interchangeable.

2. The angle of the outer ring and the diameter size of the outer raceway have been standardized. No changes are allowed during design and manufacture. So that the outer rings and inner components of tapered roller bearings can be interchanged all over the world.

3. Tapered roller bearings are mainly used to withstand combined radial and axial loads, which are mainly radial loads. Compared with angular contact ball bearings, the bearing capacity is larger and the limit speed is lower. Tapered roller bearings can withstand an axial load in one direction and limit the axial displacement in one direction of the shaft or housing.

Shipping method:

1. For small amount (GW<100KGS), we can send you by express, such as DHL, Fedex, TNT etc

2. For GW between 100KGS to 500KGS, we can send you by sea shipping or air shipping

3. For large amount (GW > 500KGS), we can send you by se

Factory Photo:

How to Place an Order:

1. Send us your bearing inquiry, including your bearing models, your quantity. If you have brand requirement, please tell us which brand do you need as well.

2. We will quote bearing price for you. Moreover, According to the quantity of goods, we will give you different options of transportation.

3. If you agree with our price, we will make proforma invoice for payment

4. After payment is done, we will start to prepare bearings and arrange shipment

Quality In Everything We Do:

1.Suppliers quality: working only with the best

Our Supplier Quality and Development (SQD) division guarantees the flawless supply of highest quality raw materials and components.
Process quality: accurate, on-time production

All manufacturing facilities employ a Lean approach in manufacturing, involving every team member in a philosophy of continuous improvement. We have state-of-the-art production lines in all our plants. The integrated manufacturing process controls enable us to check 100% of the parts at every critical production step.

2.OEM-Quality Products

We deliver our products to leading global manufacturers of transmissions, axles, differentials, and fluid pumps amongst others; these customers use our products directly or integrate them into their Original Equipment.
